Product
Specifications |
Battery of
Analyzer |
Battery
Backup Time (continuous duty) |
30 hour |
Low
Battery indication |
Yes |
Chemistry
of Rechargeable Battery |
Li-ion |
Number
of Spare Rechargeable Batteries supplied with the instrument |
0 |
Battery
Voltage |
3.7 Volt |
Power
Source |
Rechargeable
Battery |
Battery
is BIS Approved |
Yes |
BIS
Registration number for Battery under CRS of MeitY |
NA |
Display /
Indicator / Storage / Interface |
Display
Type |
TFT LCD |
Record
Memory (Minimum) |
50000 |
Display
Size |
2.4 inch |
If
yes, Capable to display the geolocation of test inspection / location |
NA |
GPS |
No |
Data
Interface |
USB |
Camera |
No |
Record
Entry |
Through
Alphanumeric Keyboard |
Availability
of audible beeper for over range, low battery etc. |
Yes |
If
yes, Capable to capture the clear image of test target |
Yes |
Record
Data Downloadable to PC |
Yes |
Minimum
Record Fields |
Full
Information as per the user's requirement such as Driver Name, Vehicle
number, inspector name, test report with time, date, geo-location, instrument
id etc. |
Environmental
/ Certification |
Name
of the Lab and Address |
NA |
Conformity
to Dry Heat test at 50 degree C for 16 hours as per IS :9000 latest |
Yes |
Test
Report Number and Date |
NA |
Conformity
to Damp heat at 40 degree C - 95% RH (cyclic test): two cycles of 16+8 hours
as per IS: 9000 latest |
Yes |
Conformity
to Cold test at - 5 / -10 / - 15 / -20 degree C (as applicable) for 4 hours
as per IS: 9000 latest |
Yes |
Availability
of Test Reports from Central Govt / NABL approved / ILAC accredited Lab to
prove conformity to the specification |
Yes |
Operating
Conditions
|
Maximum
Operating Temperature |
50 degree
Celsius |
Minimum
Operating Temperature |
-10 degree
Celsius |
Relative
Humidity Non Condensing (%) |
80 |
Physical |
Size
(mm x mm x mm) |
200 X 81 X 33 |
Weight |
250 gram |
Statutory
Requirements |
If
yes, the equipment meets the requirements of the applicable latest Central
Motor Vehicle Rules and all Govt notifications |
Yes |
Immunity
to RF interface, meets requirement as per EN:5008-/1992(emission) and
EN:50082-1:1997 (immunity) or equivalent |
Yes |
The
equipment can be used as an evidential instrument for Traffic Law
Enforcement, the instrument is handheld, portable and easy to operate |
Yes |
Technology
/ Performance |
RoHS
Compliant |
Yes |
Sensor
Technology |
Electrochemical
- Fuel Cell (alcohol specific) |
Sampling
modes |
Both Active and
Passive |
Time
required for re-calibration |
12 month |
Sampling
Error Detection |
Alarm on wrong
sampling |
Barometric
Pressure Range (hpa or millibar) |
600 millibar |
Drift
of the breath analyzer in 6 months period (mg / 100 ml BAC) |
1 |
Analytical
Response Time (At '0' level of Alcohol) |
3 second |
Warm
up Time (after putting on) |
10 second |
Easily
replaceable mouthpiece with Sputum Trap |
Yes |
Shelf
Life of Fuel Cell |
3 year |
Sample
Taking Duration |
3 second |
Sampling
Method |
Deep Lung
Exhalation Method |
Measuring
Range [mg / 100 ml BAC (Blood Alcohol Concentration)] |
0 to 500 |
Accuracy |
+/- 5 % or
better |
Analytical
Response Time for positive result |
5 second |
