Product Specifications |
Battery Of Analyzer |
Battery Backup
Time (continuous duty) |
30 hour |
Low Battery indication |
Yes |
Chemistry of Rechargeable Battery |
Li-ion |
Number of Spare Rechargeable Batteries supplied with the
instrument |
0 |
Battery Voltage |
3.7 Volt |
Power Source |
Rechargeable
Battery and also work through automobile 12 V DC Power |
Battery is BIS Approved |
Yes |
Printer |
Printer consists of Inbuilt Rechargeable Battery, Paper for
offence printouts, Charger |
NA |
Printer |
Without |
"Minimum number of printouts that can be taken with
single charge of the printer battery (Hint:- Minimum 60 prints, if 'With
Printer' May indicate '0' if not applicable)" |
0 |
Minimum number of printouts that can be taken with the
paper available with the Printer |
0 |
Type of Printer |
NA |
BIS Registration number for Printer under CRS of MeitY |
R-41131890 |
Print Resolution (dpi) |
300 |
Printer Battery is BIS Approved |
Yes |
Display / Indicator / Storage / Interface |
Display Type |
LCD |
Record Memory (Minimum) |
50000 |
Display Size |
2.4 inch |
If yes, Capable to display the geolocation of test
inspection / location |
NA |
GPS |
No |
Data Interface |
USB |
Camera |
No |
Record Entry |
Through
Alphanumeric Keyboard |
Availability of audible beeper for over range, low battery
etc. |
Yes |
If yes, Capable to capture the clear image of test target |
NA |
Record Data Downloadable to PC |
Yes |
Technology / Performance |
RoHS Compliant |
No |
Sensor Technology |
Electrochemical
- Fuel Cell (alcohol specific) |
Sampling modes |
Both
Active and Passive |
Time required for re-calibration |
12 month |
Sampling Error Detection |
Alarm on
wrong sampling |
Barometric Pressure Range (hpa or millibar) |
640
millibar |
Drift of the breath analyzer in 6 months period (mg / 100
ml BAC) |
1 |
Analytical Response Time (At '0' level of Alcohol) |
3 second |
Warm up Time (after putting on) |
5 second |
Easily replaceable mouthpiece with Sputum Trap |
Yes |
Shelf Life of Fuel Cell |
3 year |
Sample Taking Duration |
2 second |
Sampling Method |
Deep Lung
Exhalation Method |
Measuring Range [mg / 100 ml BAC (Blood Alcohol
Concentration)] |
0 to 600 |
Accuracy |
+/- 5 %
or better |
Analytical Response Time for positive result |
10 second |
The Equipment meet RFI requirement as per
EN:5008-1/1992(emission) and EN 50082-1:1997(immunity) or equivalent
requirements |
Yes |
Recovery Time at (1/2) mg/ltr |
10 second
|
