Native Resolution | WUXGA (1920 x 1200) |
Brightness | 7000 ANSI Lumens |
Contrast Ratio | 20,000:1 |
Max. Supported Resolution | 4K-UHD (3840 x 2160) @60Hz |
Native Aspect Ratio | 16:10 |
Lamp Life and Type | Lamp free design. Laser light source lasts up to 20,000 hours |
Display Type | Single chip DLP® Technology by Texas Instruments |
Chip Size | 0.67” DMD |
Throw Ratio | 7 optional lenses from 0.78:1 to 3.0-5.0:1 throw ratio range |
Zoom Ratio | Manual Zoom & Focus |
Lens Shift Range | Manual; Vertical +55%, -15%; Horizontal +/-5% |
Offset | Manual Lens Shift |
Keystone Correction | Vertical +/-30°; Horizontal +/-25° |
Speakers | 10W x 2 |
Video Compatibility | SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L), 4K-UHD |
I/O Connection Ports | VGA-In (15pin D-Sub), HDMI (x2), DVI-D, Component (5 BNC) (RGBHV) , Composite Video, Audio-In (RCA) , Audio-In (Mini-Jack), VGA-Out (15pin D-Sub), Audio-Out (RCA), RJ45 (x2: LANx1, HDBaseTx1), 12v Trigger, RS-232 (x2: In and Out), 3D-Sync (x2: In and Out), USB A (Power Only), USB B (Service), Remote Jack(wire remote) |
Dimensions (W x D x H) | 470 x 517 x 202 mm |
Weight | 25 kg |
Noise Level | 33dB/30dB (Normal/Eco. Mode) |
Power | Supply: AC 100-240V, 50/60Hz Consumption: 520W (Eco. Mode), 630W (Normal Mode), <0.5W (Standby) |
3D Ready(DLP link, PC+Video) | Yes |
Standard Accessories | VGA Cable, Quick Start Guide, Warranty Card (by region), Remote Controller (with battery), AC Power Cord |
