Specification
Display Type |
LCD |
Display Panel Diagonal size (mm) |
1397 |
Width of The Effective Display Area of The
Panel (mm) |
1271 |
Height of The Effective Display Area of The
Panel (mm) |
774 |
Backlight Technology |
LED |
Display Resolution (Pixels) |
3840X2160 |
Display Brightness (Nits) |
440 |
Display Aspect Ratio |
16:9 |
Touch interface |
Touch sensitive as well as pen driven |
Touch Technology |
Infrared optical |
Number of touch points (Number) |
20 |
Response time (milli seconds) |
8 |
Operating System Compatibility |
ANDROID 11, WINDOWS |
Number of Input HDMI ports |
3 |
Number of USB 2.0 ports (Nos.) |
1 |
Number of USB 3.0 ports (Nos.) |
4 |
Number of Audio Input ports (Number) |
1 |
Number of audio output ports (Nos.) |
1 |
Number of RS-232 C ports (Nos.) |
1 |
Number of RJ 45 ports (Nos.) |
1 |
Number of VGA-IN ports (Number) |
1 |
Number of VGA-OUT ports (Number) |
0 |
Provision of in built speakers |
Yes |
Provision for wall mounting |
Yes |
Bluetooth connectivity |
Yes |
Wi-Fi connectivity |
Yes |
Number of electronic pen or stylus to be
supplied with the board (Nos) |
2 |
Details of software provided |
ANDROID,32GB,4GB RAM |
Power Supply Voltage in AC (Volts) |
100-240 |
Power consumption (Watts) |
170 |
Operating Temperature Range (degree celsius) |
0 - 40 |
Operating Humidity (%)RH |
10- 90 |
Installation Kit to be supplied alongwith
the Panel |
Yes |
All connecting Cables and accessories to be
supplied along with the Panel |
Yes |
BIS Registration under CRS of Meity |
Yes |
BIS Registration Number & its Validity |
R-41231347 |
Availability of test reports from Central
Govt /NABL / ILAC accredited Lab covering all the parameters |
No |
Test Report Number |
NA |
Test Report date |
NA |
Name of Test lab |
NA |
Address of the Test lab |
NA |
