Display Type | LCD |
Display Panel Diagonal size (mm) | 1905 |
Width of The Effective Display Area of The Panel (mm) | 927.9 |
Height of The Effective Display Area of The Panel (mm) | 1649.7 |
Backlight Technology | LED |
Display Resolution (Pixels) | 3840X2160 |
Display Brightness (Nits) | 350 |
Display Aspect Ratio | 16:9 |
Touch interface | Touch sensitive as well as pen driven |
Touch Technology | Infrared optical |
Number of touch points (Number) | 10 |
Response time (milli seconds) | 8 |
Operating System Compatibility | Win,Mac,Android |
Number of Input HDMI ports | 3 |
Number of USB 2.0 ports (Nos.) | 5 |
Number of USB 3.0 ports (Nos.) | 1 |
Number of Audio Input ports (Number) | 1 |
Number of audio output ports (Nos.) | 0 |
Number of RS-232 C ports (Nos.) | 1 |
Number of RJ 45 ports (Nos.) | 1 |
Number of VGA-IN ports (Number) | 1 |
Number of VGA-OUT ports (Number) | 0 |
Provision of in built speakers | Yes |
Provision for wall mounting | Yes |
Bluetooth connectivity | No |
Wi-Fi connectivity | Yes |
Number of electronic pen or stylus to be supplied with the board (Nos) | 2 |
Details of software provided | EZwrite 5.0 |
Power Supply Voltage in AC (Volts) | 100-240 |
Power consumption (Watts) | 239 |
Operating Temperature Range (degree celsius) | 0°C ~ 40°C |
Operating Humidity (%)RH | 20% ~ 80% RH |
Installation Kit to be supplied alongwith the Panel | Yes |
All connecting Cables and accessories to be supplied along with the Panel | Yes |
BIS Registration under CRS of Meity | Yes |
BIS Registration Number & its Validity | R-41177997 |
Availability of test reports from Central Govt /NABL / ILAC accredited Lab covering all the parameters | No |
Test Report Number | NA |
Test Report date | NA |
Name of Test lab | NA |
Address of the Test lab | NA |
On Site OEM Warranty (Year) | 3 |
